Elevate Plastotech Industries manufactures reliable Monolayer Blown Film Lines designed for consistent film quality, efficient production, and flexible processing of LDPE, LLDPE, and HDPE materials. As a Monolayer Blown Film Line Manufacturer in Ahmedabad, Monolayer Blown Film Line Supplier in Gujarat, and Monolayer Blown Film Line Distributor in India, the company provides extrusion systems that melt polymer resin and form it into a continuous single-layer tubular film through a circular die. The film bubble is then cooled, flattened, and wound into rolls for further use, supporting stable output and uniform film production.
EPIBL Series Technical Specifications
- EPIBL-45
- Lay Flat Width: 300–700 mm
- Film Thickness: 20–80 μm
- Maximum Output: 45–50 kg/hr
- Screw Diameter: 45-G
- EPIBL-55
- Lay Flat Width: 400–1000 mm
- Film Thickness: 20–80 μm
- Maximum Output: Up to 65 kg/hr
- Screw Diameter: 55-G
- EPIBL-65
- Lay Flat Width: 600–1200 mm
- Film Thickness: 20–100 μm
- Maximum Output: 80–90 kg/hr
- Screw Diameter: 65-G
- EPIBL-75
- Lay Flat Width: 800–1400 mm
- Film Thickness: 40–150 μm
- Maximum Output: 120–130 kg/hr
- Screw Diameter: 75-G
- EPIBL-90
- Lay Flat Width: 900–1600 mm
- Film Thickness: 50–150 μm
- Maximum Output: 170–180 kg/hr
- Screw Diameter: 90-G
These models offer flexible configurations for different film widths, thicknesses, and production capacities.
How Does a Monolayer Blown Film Line Work?
The process starts with feeding plastic granules into the extruder, where controlled heating melts and mixes the material. The molten polymer is then pushed through an annular die to create a tubular film. An air ring cools and stabilizes the bubble before nip rollers flatten it and the winding unit forms finished rolls. As a Monolayer Blown Film Line Supplier in Gujarat, Elevate Plastotech Industries provides machines designed for smooth operation and dependable production.
Main Process Stages
- Resin feeding and controlled melting
- Extrusion through an annular die
- Bubble inflation and cooling
- Bubble stabilization
- Flattening through nip rollers
- Optional corona treatment
- Film winding into finished rolls
Key Features and Benefits
The Monolayer Blown Film Line Supplier in Gujarat offers equipment designed with practical production features, including:
- Single extruder configuration for monolayer film production
- Precision annular die head
- Efficient air-ring cooling system
- Bubble cage for improved film stability
- Microcomputer-controlled operation
- Touch-screen control interface
- Screen changer for improved melt filtration
- Consistent film thickness and width
- Suitable for different polyethylene materials
- Efficient and continuous film winding
These features make the Monolayer Blown Film Line Distributor in India solutions suitable for manufacturers seeking dependable film extrusion with controlled operating parameters.
Applications of Monolayer Blown Film Line
A Monolayer Blown Film Line can be used to manufacture a wide range of flexible plastic films and packaging products. Elevate Plastotech Industries supplies equipment suitable for:
- Shopping and grocery bags
- T-shirt bags
- Garbage and refuse bags
- Courier bags
- Food packaging films
- Dairy and frozen-food packaging
- Fresh-produce packaging
- Lamination films
- Woven sack liners
- Agricultural films
- Greenhouse and mulch films
- Industrial packaging films
- Heat-sealed packaging applications
As a Monolayer Blown Film Line Distributor in India, Elevate Plastotech Industries supports manufacturers across different plastic-processing and packaging applications.
Need a Monolayer Blown Film Line? Contact Elevate Plastotech Industries for model details, pricing, and customized production solutions.
FAQs
1. What materials can a Monolayer Blown Film Line process?
A Monolayer Blown Film Line can process commonly used polyethylene materials such as LDPE, LLDPE, and HDPE. Material selection depends on the required film properties and application.
2. What film thickness can the EPIBL series produce?
The available EPIBL models cover film thickness ranges from approximately 20 to 150 microns, depending on the selected model and production configuration.
3. How do I choose the right Monolayer Blown Film Line?
The right machine depends on required film width, thickness, material, production output, and application. A Monolayer Blown Film Line Manufacturer in Ahmedabad can help match the machine configuration to your production requirements.
